1
Fitting the Analogue Timer (to a boiler without timer
housing)
If the boiler does not contain the timer housing,
follow the instructions below.
If the boiler does contain the boiler housing, follow
the instructions detailed in section 2.
1.1
Remove the front casing and hinge down the control
box.
1.2
Remove the timer blanking plate at the bottom of
the boiler by pressing the retaining latches, using an
appropriate tool e.g. a flat bladed screwdriver.
Carefully remove the blanking plate.
The timer kit harness and plug are attached to the
blanking plate to aid fitting of the timer.
Unplug the harness from the blanking plate by pressing
the retaining catch.
TIMER
BLANKING
PLATE
use a flat bladed screwdriver here
to remove the blanking plate
TIMER KIT HARNESS
AND PLUG
RETAINING
CATCH
TIMER
BLANKING
PLATE
1.3
Fit the plug to the timer kit socket, the plug will only fit
one way.
18 17
16
15
14
13
12
11
8
19
20
21
22
23
24
10
9
7
6
5
4
3
2
1
TIMER KIT SOCKET
1.4
Glow Worm Flexicom 18sx Manual
Locate the timer kit body into the space left by the
blanking plate on the underside of the boiler.
TIMER AND
HOUSING
1.5
Ensure good positioning of the harness then replace
control box and front casing.
1.6
Glow Worm Flexicom 30 Sx Manual
Re-establish mains and gas supply to the boiler.
When using the timer, push the bottom of the timer kit
slide to release it from it’s housing, allow the timer to
fall naturally, it’s movement is controlled by a damper,
do not pull the timer down. To re-engage the timer,
push gently upwards until it clicks into position.
0020136593 - 01/12 - Glow-worm
- 3 -
INSTALLATION
EN
